Cruise Missiles Flying over your Head

As I was quite vocal in questioning the decision of Saab to opt for the Taurus KEPD 350 as their heavy cruise missile, I was not overly surprised when Saab contacted me and asked if I wanted to discuss the choice as well as their bid more generally. It turned into a rather interesting brief, with representatives from both Saab and TAURUS Systems GmbH (owned to 67% by MBDA Deutschland GmbH and 33% by Saab Dynamics AB).

Saab further discussed the extent to which Finnish-Swedish cooperation and possible synergies play into the bid. Saab has not only run all company simulations of scenarios based on the FDF requirements to find the best setup for Finland, but in a step further they have also run the same simulations with Finland and Sweden being allied to see how this setup would work if Finland wouldn’t have to go at it alone. The BAFO includes not only Saab’s offer, but also drafts for a number of political agreements for closer defence cooperation, such as for a shared situational air picture benefiting from both countries operating not only the same aircraft types, but similar versions of these aircraft. With the Finnish requirement to align the configuration of the eventual HX-winner with the main user, this include not only the earlier announced Swedish political decision to align their 39E configurations with the Finnish requests (including long-range precision strike and “enhanced electronic attack capability”), but also operating similar GlobalEye-configurations. In a change compared to earlier announcements, Bombardier keeping the Global 6000 in production allow Saab to use the same platform for both Finland and Sweden as is currently in service with the UAE. This opportunity saves quite a bit of certification and R&D costs compared to the earlier indicated change to Global 6500 as the basic platform for the GlobalEye, which frankly wouldn’t give too much of an improvement. An improved wing and new Rolls-Royce BR710 Pearl gives better hot and high performance as well as better range and endurance for the newer Global 6500, but for a Finnish scenario the Global 6000 should provide plenty enough of performance and the up-front savings can be better spent elsewhere.

Saab is very much in agreement with Lockheed Martin that having a single-configuration fighter fleet is preferable due to the flexibility it offers when it comes to for example fleet management and readiness. The required capability to be able to pull it off is in Saab’s case based on the brand new integral electronic warfare system – which carries on the tradition of the highly respected JAS 39C/D EW-system – as well as the EAJP offering the wider frequencies and high output power needed to counter not only fire control radars but also other parts of the electro-magnetic spectrum. This goes hand in hand with Saab’s (and Sweden’s) long history of advanced datalinks, which means that Swedish fast jet tactics place a very high emphasis on the four-ship formation as a tactical unit as opposed to the traditional focus on the lead-wingman pair, and allowing e.g. for passive triangulation (another area where Saab and Lockheed Martin is in agreement is that this is a very cool and useful feature).

But none if this is really earth-shattering news. What about that cruise missile?

A Taurus KEPD 350 impacting a concrete target. Picture courtesy of Taurus Systems

The reason behind the Taurus KEPD 350 losing out to AGM-158A JASSM for integration on the Finnish Hornet-fleet was discussed, and Saab responded in rather general terms.

Many factors were behind the original JASSM choice, how flexible were the US authorities in allowing integration of Taurus on Hornet? I don’t know.

Having said that, Saab wasn’t interested in commenting on how flexible the US might be in integrating JASSM on the 39E Gripen. They did however (correctly) point out that the Finnish JASSM inventory is set for either retirement or a mid-life update by the time the Hornets retire, and that technically there are no issues with integrating the weapon.

Still, there’s no tears shed by Saab over the (forced?) choice of Taurus KEPD 350, as they are quick to point out that the weapon is extremely potent, and offering a rather different design philosophy compared to the US offering. Interestingly many of the design choices actually do mirror the design choices of the Gripen-platform itself, lending some credibility to Saab’s argument that it is the superior weapon for a Gripen-fleet in Finnish service.

The basic idea is that radars evolve, and as such the value of stealth will diminish over time. Physics, however, remain surprisingly constant, and as such flying at very low level under the radar horizon is bound to work equally well in 2060 as it does today. This is then coupled with a highly redundant navigation system based on INS, GPS, a radar altimeter, and an IIR-sensor that together open up for image- and terrain-based navigation. This is couple with an advanced mission planning software to ensure that the weapon will get where it needs to be, which take into consideration the overall situation including threats, terrain, friendly forces, and weather.

The mission planning is actually a really interesting feature, as not only is it reportedly very precise (a requirement for being able to fly at extremely low altitude), but by simulating the entire strike it is able to run detailed Monte Carlo-simulations which take into account for example changes in the weather conditions or how the situation for the later missiles released changes with earlier missiles in the strike hitting their targets. The idea is to ensure economy in weapons use, and avoid wasting missiles in saturation attacks. This is a common theme for the marketing of the weapon, promising “low acquisition costs combined with low run-time costs”.

At the heart of this capability is the 480 kg warhead that sport a dual-charge layout with a pre-charge and a penetrator, resulting in what Taurus claim is “unmatched concrete penetration capability” and crucially allows the missile to stay low and attack also hardened targets at shallow dive angles instead of the more classic pop-up profile. But while the bunker-busting features is what the warhead is best known for, specialised fuzes allow additional flexibility such as overflight airburst modes. And again, flexibility further adds to the cost-efficiency.

In short Taurus claims that several factors add up to ensure that more enemy stuff will go boom for the same amount of money compared to JASSM (and yes, continuing the trend after the BAFOs both Taurus and Saab are naming their competitors as opposed to talking about hypothetical comparable systems). In addition, the weapon reportedly outranges the current AGM-158A JASSM in having approximately 600 km range if released at altitude (usual caveats apply).

Interlude: The saga of the JASSM-ER continues

Back in February it seemed the JASSM-version offered to Finland was the weapon originally designated AGM-158D JASSM-XR. However, turns out there’s another twist in USAF weapons procurement that came to light a while ago, as there are in fact a number of different JASSM-ER and -XR versions. The ‘original’ JASSM-XR apparently is still in development though it is now designated AGM-158D JASSM-ER, but it is pushed back as a version of the -ER designated the AGM-158B-2 is entering production. This weapon which is offered to Finland feature the more advanced datalink of the -XR but lack the improved wing (and hence not reaching the same range). At the same time, the US Navy scrapped the JSOW-ER and is focusing on an JASSM-ER version that will feature some components of the AGM-158C LRASM allowing it to also be used as an anti-ship missile, meaning that in total there seems to be at least six different versions of the JASSM either having reached production status or in different stages of development, four of which are designated JASSM-ER (AGM-158B, AGM-158B-2, AGM-158 ‘Navy-version’, and AGM-158D, with the other two being the AGM-158A and the anti-shipping AGM-158C LRASM). Range numbers of the AGM-158B-2 are somewhat obscure, but likely close to the original AGM-158B at around 930 km.

In any case, both the AGM-158B and Taurus KEPD 350 would offer significant increases to the ranges of Finnish air-launched weapons, and while cutting the Jaroslavl-Vologda railroad might be easier with the AGM-158D, a conflict would see no shortage of potential targets within 500 km of the border.

Render of Taurus KEPD 350 showing what is by now a the standard layout of weapons in its class with a boxy fuselage, pop-out wings and rear-mounted fins and engine. Picture courtesy of Taurus Systems

Back to Gripen, the aircraft has been in the headlines recently in Sweden due to budgetary discussions. Saab played down these, noting that none of the reported cost overruns are directly tied to the development of the 39E, but rather they stem from political infighting, earlier overly-optimistic Swedish Armed Forces budgets, and so forth. Not having seen the original documents behind the headlines it’s hard to comment further, though it arguably wouldn’t be the first time there has been a refusal from Swedish politicians to recognise what defence capabilities actually cost.

However, for HX the question is largely moot, as Saab is very much in agreement with Boeing in that now the best and final offers really are the final offers, and that by now everything is set if not in stone then at least ink. The Swedish proposal is firm with regards to contents, price, as well as delivery, and as such it is somewhat different from the FMS framework. And there won’t be any major changes or ‘up to’-wordings.

We have been puzzled by some of the reactions or comments swallowed by the media, there is not ‘later’

We’ll have to see what Lockheed Martin has to say about that.

Saab also confirmed that there are further weapon types in the offer that haven’t been disclosed. While there certainly are some who would like to believe this to be the RBS 15, in reality it is likely to be about gravity bombs.

A more cut-throat statement was that not only is Saab certain that the robustness and availability of the Gripen ensure that “with margin there will always be more than 50 Gripens available in peacetime”, their business intelligence based on open sources gives that for “the competition” the corresponding number would be about 35 fighters available. And that is before including the fact that Gripen would be flying less due to the GlobalEyes providing a better situational picture.

We’ll have to see what “the competition” has to say about that.
